TROLMASTER - LIGHTING CONTROL ADAPTER F | 0-10V FOR DIMLUX, LUMATEK, ORTHOLED AND OTHERS
TrolMaster's Hydro-X system can control most horticultural lighting fixtures sold on the market today. Most lighting manufacturers offer the possibility of controlling their lighting systems using...
Recalculation in progress … TrolMaster's Hydro-X system can control most horticultural lighting fixtures sold on the market today. Most lighting manufacturers offer the possibility of controlling their lighting systems using so-called low-voltage control. That low-voltage control can take many forms and communication protocols. TrolMaster produces several types of lighting adapters (LMA units) that allow the Hydro-x to control lights using their low-voltage control option.
NOTE: Each LMA-14 can control up to 40 HID lights or 24 LEDs. Additional LMA-14 adapters can be used with the SPH-1 to control as many lights as required.
*When used with Fluence Spyder 2x/2i 277V fixtures, no more than 12 LEDs per LMA-14
This LMA-14 lighting adapter is specially designed to control HIDs such as Gavita / Nanolux / Luxx / Growers Choice / Illuminar / PL and LEDs such as Ortoled, Lumatek, Fluence and Lumen-King / Next light / Photobio / Ortoled /Dimlux with RJ12 connection
Features Lighting Control Adapter F from TrolMaster:
- Power LED indicator
- Converts digital signal to analogue signal
- Perfect connection to Hydro-X with RJ12 cable
Technical Specifications TrolMasterLighting Control F Adapter
- Output voltage: 0 ~ 11.5 V.
- Maximum current: 0.2 A.
- Working environments: temperature 32-122° F, humidity = 90%.
- Packaging dimensions: 156 mm (W) x 83 mm (L) x 30 mm (H)
- GW by weight: 0.05 kg
Package contents:
- 1 x Lighting Control Adapter F (LMA-14)
-
